Overview
If you're looking to improve the handling of your Audi B9 Q5 / SQ5, this is the best place to start! These cars have a lot more body roll than what's to be desired factory, and the stock sway bars don't quite do enough to keep the body from understeering.
TGK Motorsport Sway bars are made from solid spring steel to give you the best strength in a smaller size, while helping eliminate understeer from this platform.
Specifications
| Front Bar Diameter | 32MM Solid Spring Steel |
| Rear Bar Diameter | 30MM Solid Spring Steel |
| Front Mounting | OEM Bushings & Mounts |
| Rear Mounting | Black Anodized 6061-T6 Billet Brackets |
| Finish | Powder Coated for Corrosion Resistance |
| Special Features | Check Valve Grease Port (Rear) |
Stiffness Options
| Stiff | Stiffer | |
|---|---|---|
| Front Stiffness Increase | 128% | 169% |
| Rear Stiffness Increase | 139% | 188% |
Features & Benefits
✓
Solid Spring Steel ConstructionSuperior strength in a smaller diameter for optimal performance and weight savings.
✓
Reduced Body RollSignificantly improves handling by minimizing unwanted chassis movement through corners.
✓
Eliminates UndersteerEnhanced front-to-rear balance reduces the factory understeer characteristics of the platform.
✓
Corrosion Resistant FinishPowder coating provides long-lasting protection against environmental elements.
✓
OEM IntegrationFront bar utilizes factory bushings and mounting points for seamless installation.
✓
Billet Aluminum Rear BracketsCNC-machined 6061-T6 brackets with grease ports for enhanced durability and serviceability.
Frequently Asked Questions
What's the difference between the stiff and stiffer settings?
The stiff setting provides 128% front and 139% rear stiffness increase for improved handling with reasonable comfort. The stiffer setting offers 169% front and 188% rear increase for maximum performance and track use.
Will this affect my ride quality?
Sway bars primarily affect body roll during cornering and have minimal impact on straight-line ride comfort compared to other suspension modifications.
Can I install just the front or rear bar?
While each bar can be installed separately, the complete front and rear kit provides the best balance and handling improvement for the B9 platform.
Do I need special tools for installation?
Basic hand tools are sufficient for installation. The front bar uses OEM mounting points while the rear includes all necessary billet brackets.
What's the purpose of the grease port on the rear brackets?
The check valve grease port allows for easy maintenance of the rear bar bushings, extending service life and maintaining optimal performance.
